High-Pressure Performance for LPG Applications
The JETAX Floating Ball Valve is a versatile solution designed to meet diverse industrial needs. Available in sizes ranging from NPS 1/2″ to 12″, and pressure ratings from CLASS 150 to 1500, this valve provides reliability across a spectrum of applications. Crafted from materials such as WCB, LCB, CF8, CF8M, A105, LF2, F304, F304L, F316, and F316L, it ensures robust performance and longevity. Compliant with API 608, API 6D, and BS 5351 standards, its face-to-face dimensions follow ASME B16.10, API 6D, and BSEN 559 guidelines. The end connections adhere to ASME B16.5 and BSEN 1092, while stringent testing, in accordance with ISO5208, API 6D, and BSEN 12266, guarantees its reliability. The Floating Ball Valve is versatile in operation, with options for manual control, worm gear, electric actuator, and pneumatic actuator methods, providing flexibility and efficiency in fluid control systems.
Applications Area
Oil & Gas
Oil Transportation
Chemical
LNG
Function
Fluid Transfer – LPG Pumping – High Differential Pressure Applications
Standards
ASME B16.5
API 6D
ISO 9001
IEC/ATEX Ex d IIB T4 Gb
IP55
ANSI / DIN Class 300
Mounting Options
- Direct drive with coupling
- Best drive
- Directly mounted with a C-face electric motor
Key Features
High differential pressure capability – Ideal for underground tanks
Non-pulsating flow – Smooth, quiet operation
Precision floating impeller – Optimized for efficient energy transfer
Heavy-duty bearings – Built for long service life under continuous operation
Silicon carbide mechanical seal – Exceptional sealing with minimal maintenance
Compact, field-serviceable design – Easy seal replacement without full disassembly
Dual mounting options – Direct drive or C-face motor installation
Available with ASME or DIN Class 300 flanges
Technical Specification
| Model | JXTP150 |
|---|---|
| Inlet | 1-½” ASME Class 300 RF (DIN optional) |
| Outlet | 1” ASME Class 300 RF (DIN optional) |
| Max Pressure | 400 psig (27.6 bar) |
| Max Flow Rate | 33.8 GPM (128 L/min) |
| Speed | 3450 RPM @ 60 Hz / 2880 RPM @ 50 Hz |
| Max Power | 20 HP (15 kW) |
| Temperature Range | -25°C to 107°C (-13°F to 225°F) |
| Mounting | Direct drive or C-face motor |
| Certification | Ex d IIB T4 Gb, IP55 compliant |
